| Mobile PC Barebone - Processor |
| Supports Central Processor Unit:
| Intel Celeron-M
Intel Core2 Duo |
| CPU Socket Standard:
| Socket P |
| Max. CPU Bus Clock Rate:
| 800 MHz |
| Chipset:
| Intel PM965 Express |
| Architecture Features:
| Intel® Turbo Memory |
| Mobile PC Barebone - Memory |
| Memory Technology:
| DDR2 SDRAM |
| Memory Speed:
| 533MHz(PC2-4200)
667MHz(PC2-5300) |
| Memory Form Factor:
| SODIMM 200-pin |
| Maximum Installable System Memory Storage Capacity:
| 4096 MB |
| Memory Slot Total Quantity:
| 2 |
| Mobile PC Barebone - Storage Hard Drive |
| Hard Drive Type:
| Portable |
| Supports Data Channel:
| SATA |
| Rotational Speed:
| 7200 rpm |
| Mobile PC Barebone - Storage Optical Drive |
| Optical Drive Type:
| DVD±RW/DVD+R9/DVD-RAM |
| Possible Optical Drive Type:
| CD-RW
DVD-ROM |
| Optical Drive Location:
| Internal |
| Optical Drive Interface Type:
| ATAPI |
| Mobile PC Barebone - Display |
| Display Technology:
| TFT Active Matrix |
| Possible Display Diagonal Length&Resolution:
| 15.4" WXGA (1280x800) |
| Mobile PC Barebone - Audio Output |
| Compliant Audio Standards:
| Intel HD Audio |
| Mobile PC Barebone - Video Output |
| Video Chipset:
| Nvidia GeForce Go 8600 |
| Video Memory Type:
| Video Controller Memory |
| Installed Video Memory Storage Capacity:
| 256 MB |
| Mobile PC Barebone - Modem |
| Modem Type:
| Fax/Modem |
| Modem Form Factor:
| integrated |
| Maximum Modem Bit Rate:
| 56600 bps |
| Maximum Fax Bit Rate:
| 14400 bps |
| Analog Modulation Protocol:
| V.90
V.92 |
| Mobile PC Barebone - Networking Specifications |
| Networking Type:
| Network Adapter |
| Networking Form Factor:
| Integrated |
| Data Link Protocol Supports:
| Gigabit Ethernet/Fast Ethernet/Ethernet |
| Optional Data Link Protocol Supports:
| Bluetooth
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n |
| Mobile PC Barebone - Slot Provided |
| Provides Expansion Slot Standard:
| Express card |
| PCI Express Slot Quantity:
| 1 |
| Mobile PC Barebone - Interface Provided |
| Modem Interface Quantity:
| 1 |
| USB 2.0 Interface Quantity:
| 4 |
| VGA Interface Quantity:
| 1 |
| Microphone-In Interface Quantity:
| 1 |
| LAN Interface Quantity:
| 1 |
| IEEE-1394 Interface Quantity:
| 1 |
| S-Video Output Interface Quantity:
| 1 |
| Mobile PC Barebone - System |
| Built-in Devices:
| Touchpad
Card Reader
Stereo Speakers
2.0 M-pixel Video module |
| Flash Types Supported:
| MS
MS PRO
MMC/SD |
| Security Features:
| Keyhole Lock
Password Protection |
| Certifications:
| roHS |
| Mobile PC Barebone - Software |
| Platform Compability:
| PC |
| Supported Operating System:
| Windows XP Home
Windows XP Professional
Windows Vista Home Basic
Windows Vista Home Premium
Windows Vista Business
Windows Vista Ulitmate |
| Mobile PC Barebone - Power |
| Power Device Location:
| External |
| Input Voltage:
| AC 90-264 V |
| Input Frequency:
| 47/63 Hz |
| Maximum Output Power:
| 90 W |
| Mobile PC Barebone - Battery |
| Battery Technology:
| Lithium Ion |
| Battery Installed Quantity:
| 1 |
| Maximum Battery Supported Quantity:
| 1 |
| Battery Current Capacity:
| 5200 mAh |
| Mobile PC Barebone - Dimensions&Weight |
| Nominal Weight:
| 2.7 kg |
| Mobile PC Barebone - Additional Info |
| Package Type:
| OEM |
